Application of space frame support for space frame processing

The difficult design concept of space frame processing is the design concept of space frame support.

The space frame bracket must be entered. Therefore, how to calculate the elastic stiffness is very important. Many space frames processing designers do not distinguish the stiffness of independent column supports, round beam supports and substructures, but simply take the default value of 0.3KN/mm. The result is the stiffness of the space frame support frame. Assuming that it is separated from the actual structure, the space frame structure design department is safe. In MSTCAD, when the software inputs the substructure into the collaborative calculation, it must correctly calculate the elastic stiffness of the support body and the lateral stiffness of the substructure, and calculate the same elastic stiffness.

If the brackets are too close and one bracket is under tension, the pressure on the other bracket will increase. In the same project, the existing stretch stents have pressure stents. This phenomenon increases the difficulty of stent design. Therefore, cancel the brackets that generate tension, and the more brackets, the better.
